Philips 70W LED Street Light Cool White 6500K | BRP274 LED84 CW M2 SLR PSU SPD S2 | IP66 Waterproof
- Energy Efficient 70W LED
- Cool White Street Illumination
- Integrated Surge Protection SPD
- Durable IP66 Outdoor Housing
- Long Life Low Maintenance
Authorised dealer of Philips Lighting
About This Item
Philips 70W LED Street Light Cool White 6500K | BRP274 LED84 CW M2 SLR PSU SPD S2 | IP66 Waterproof
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Philips |
| Model | BRP274 LED84 CW M2 SLR PSU SPD S2 |
| Wattage | 70 W |
| Light Colour | Cool White (5700K) |
| IP Rating | IP66/IK08 (dust & water protection) |
| Frequency | 50 Hz |
| Optics. | SLR (street light road optics) |
| System Efficiency | 120 lm/W |
| Application | Municipal, industrial, commercial outdoor lighting |
| Generic Name | LED STREET LIGHT |
| Driver | MP PSU (high-efficiency) |
| Input Voltage | 120V-270V |
| Lumens Flux | 8400lm |
| Material | Aluminium |
| Mounting | Standard pole or bracket mounting |
| Lifetime | 50,000 hour(s) |
| Housing Material | Die-cast aluminium with tempered glass |
| Surge Protection | 4 kV |
| 12NC | 919615897366 |
| Warranty | 2 Years on-site |
The Philips BRP274 LED84 CW M2 SLR MP PSU SPD S2 (919615897364) is a high-efficiency LED street lighting luminaire designed for roads, pathways, and outdoor public spaces. It combines 70W cool white LEDs with advanced optics and a robust PSU & SPD protection, ensuring long life, energy savings, and reliability under tough outdoor conditions.
This street light features Philips Signify quality, optimized for municipal, industrial, and commercial outdoor lighting projects, and helps reduce power bills while providing uniform illumination for safety and visibility.
Key Features
-
70W LED Street Light – Efficient replacement for conventional street lights
-
Cool White (≈5700–6500K) Light – Clear visibility and security
-
Integrated Surge Protection (SPD S2) – Safeguards against voltage spikes
-
Reliable SLR MP PSU – Consistent performance & long life
-
Durable IP66 Housing – Dust and water resistant
Ideal For
-
Urban & rural street lighting
-
Industrial complexes & campuses
-
Pathways, parking areas & public parks
-
Perimeter lighting for factories & warehouses
-
Municipal & infrastructure lighting projects
Benefits
-
Energy savings vs sodium or CFL street lights
-
Cool white light improves road safety
-
Long lifespan reduces maintenance costs
-
Integrated SPD ensures reliability
-
Philips trusted quality & performance
Choose the Philips BRP274 LED84 Street Light for an energy-efficient, durable, and visually comfortable lighting solution that meets the highest standards of outdoor illumination.
Subtle Sophistication, Radiant Results
Let Lighting transform your space with understated brilliance. Lighting redefines elegance with lighting solutions that blend seamlessly into any décor. Designed for modern spaces, our lights offer understated style while delivering powerful, radiant illumination.
Choose the Right Light Color
Choose the perfect lighting for your space! Our LED solutions offer colour temperatures ranging from 3000K to 6500K. For a cosy, warm glow, go with 3000K. If you prefer a bright, cool white lighting, then 6500K is the way to go. For Natural white go with 4000K.
Frequently Asked Questions
Get Your Queries Answered
Fundamental Lighting Terms
Lumen (lm):
A lumen is the unit of luminous flux, representing the total amount of visible light emitted by a light source.
Efficacy (lm/W):
Efficacy measures how efficiently a lighting source converts electrical power (watts) into visible light (lumens). Higher efficacy indicates better performance. For example, LEDs can exceed 150 lm/W, whereas traditional incandescent lamps (GLS) offer around 10 lm/W, and compact fluorescent lamps (CFLs) about 60 lm/W.
Lux (lm/m²):
Lux is the unit of illuminance and indicates the amount of luminous flux distributed over a given area (lumens per square meter). Different applications require different lux levels; for instance, task-oriented areas such as kitchens or sewing stations demand higher lux values than general areas like corridors or lobbies.
Correlated Color Temperature (CCT, °K):
CCT describes the color appearance of a light source, expressed in degrees Kelvin (K). Light can range from warm (yellowish), to neutral (off-white), to cool (bluish white), depending on its temperature rating.
Color Rendering Index (CRI):
CRI measures the ability of a light source to render colors accurately compared to natural light. A high CRI (close to 100) indicates that objects appear more true to life, similar to how they would look under sunlight. A lower CRI may cause colors to appear distorted or unnatural.
Beam Angle:
Beam angle refers to the spread of light emitted from a source. A narrow beam (e.g., spotlights) provides focused illumination, ideal for highlighting specific features. A wider beam is better suited for general lighting, creating a more diffuse and ambient effect.
What is LED Lighting?
LED lighting refers to the use of Light Emitting Diodes (LEDs) as a source of illumination. An LED is a semiconductor device that emits light when an electric current passes through it. Unlike traditional lighting technologies such as incandescent or fluorescent lamps, LEDs do not rely on filaments or gas discharge to produce light.
LED lighting is known for its high energy efficiency, long lifespan, durability, and low maintenance requirements. It is available in a wide range of color temperatures, intensities, and form factors, making it suitable for a variety of residential, commercial, and industrial applications.
Benefits of LED Lighting
a. Energy Efficiency:
LEDs consume up to 50% less energy than CFLs, resulting in substantial energy savings and lower electricity bills.
b. Long Lifespan:
LED lights have an exceptionally long operational life, often exceeding 50,000 hours, which greatly reduces maintenance and replacement costs.
c. No Harmful Emissions:
LEDs do not emit ultraviolet (UV) or infrared (IR) radiation, making them safer for sensitive materials and human health.
d. Environmentally Friendly:
LEDs are free from hazardous substances such as mercury, making them a safer and more eco-friendly lighting option.
e. Versatile Color Options:
LED technology allows for the production of millions of color variations, enabling dynamic and customizable lighting solutions for various applications.
How LEDs life is defined?
Unlike conventional lamps that tend to fail suddenly, LEDs gradually depreciate in light output over time. The lifespan of an LED is typically defined by the point at which its luminous flux decreases to 70% of its original output—commonly referred to as L70. This gradual decline ensures more predictable performance and allows for timely maintenance or replacement planning.
Significance of 50000 hrs life
4 hr daily operation : 34 yrs
8 hr daily operation : 17 yrs
12 hr daily operation : 11 yrs
24 hr daily operation : 05 yrs
Challenges with LED Lighting
LEDs are very sensitive to temperature & also produce a lot of heat during operation. This heat should be removed from system to maintain the junction temperature within prescribed limits.
LED are point sources so are prone to cause glare if the optics is not properly designed.
What is the role of heat sink?
Heat sink is required to dissipated heat generated by LEDs during operation. Since ambient temperature in India varies from – 5 0C to + 55 0C so the heat sink design should ensure effective thermal management under all circumstances. It should be made of high grade aluminum & should have no pores (like in gravity die cast heat sinks) providing resistance to heat flow. Garnet uses aluminum pressure die cast or extrusion heat sinks.
